Name：VOYAGE five-axis bridge cut

Details

Wei Zhi five-axis bridge cut. Using microcomputer control system, can realize manual programming, or PC programming and other programming methods, automatic completion of processing operations. Can be convenient for cutting, edge grinding, grooving, kitchen table processing, shaped processing and other occasions.

Product features

1. Photographing, typesetting and positioning, and automatic measurement of plate thickness and tool size.

2. Use good computer system control, simple operation, high efficiency.

3 choose good quality electrical appliances, long service life, low maintenance cost

4. The native supports one-click transformation in multiple languages.

Technical Parameters and Price

Programming method	Manual programming
Programming method 2	CAD
Control method	CNC
Main motor power	11kw
Working voltage	380V-3phase/50HZ
R.P.M	6000r/min
Blade size	500mm
X-axis working stroke	3500mm
Y-axis working stroke	2000mm
Z-axis working stroke	260mm
A-axis working stroke	360°
B-axis working stroke	0-90°
Cutting thickness	100mm
Processing precision	0.2mm
Working table size	3500*2000mm
Tilting working table	YES
Camera	YES
Overall size	630749253414mm
Weight	*6500*KG
